2024 Нов режим на погон на камиони Howo Dump 6x4

Fumin factory provides quality 2024 new HOWO dump truck drive mode 6X4 for customers.

2024 new HOWO dump truck drive mode 6X4

Drive form 6X4

Wheelbase 3825+1350mm

Engine Weichai WP12.420E201

Gearbox Sinotruk 10-speed gearbox

Rear axle speed ratio 5.26

Body length 8.49 meters

Body width 2.55 meters

Body height 3.45 meters

Front wheelbase 2041mm

Rear wheelbase 1860/1860mm

Vehicle weight 12.5 tons

Rated load: 12.37 tons

Total mass 25 tons

Tonnage level heavy truck

Approach angle 17 degrees

Departure angle 32 degrees

Place of Origin: Jinan City, Shandong Province

Note: Optional: four-way cameras;

Engine parameters

Engine model Weichai WP12.420E201

Engine brand Weichai

Number of cylinders: 6 cylinders

Fuel type Diesel

Displacement 9.5L

Emission Standard Country II

Maximum horsepower 420 horsepower

Maximum output power 316kW

Maximum torque 1900N·m

Maximum torque speed 1200-1300rpm

Rated speed 1900rpm

Engine type: inline, direct injection

Carton parameters

The cargo box is 5.6 meters long

Cargo box width 2.35 meters

Cargo box height 1.2 meters

Cab parameters

Number of passengers allowed: 2

Gearbox parameters

Gearbox model Sinotruk 10-speed gearbox

Gearbox brand China National Heavy Duty Truck

Forward gear: 10th gear

Number of reverse gears: 2

Chassis parameters

Frame size 8+5mm

Allowable load of front axle is 7000kg

Rear axle description HC16T

Allowable load of rear axle: 18000 (two-axle group) kg

Speed ratio 5.26

Number of spring leaves 11/12

fetal

Tire specification 12.00R20 16PR

Number of tires: 10
